Autel EVO II Dual 640T Rugged Bundle V3
Review: 5 - "A masterpiece of literature" by , written on May 4, 2006
I really enjoyed this book. It captures the essential challenge people face as they try make sense of their lives and grow to adulthood.
Categories

Autel EVO II Dual 640T Rugged Bundle V3

Available: In Stock
¥44,121.00
  • Order within

640x512 25Hz New Thermal Imaging Sensor

Equipped with a 640 x 512 high-resolution thermal imaging camera featuring a 13mm focal length lens and 16x digital zoom, it is easier than ever to observe distant targets. The system uses a new image processing algorithm, making thermal details clearer and more discernible than other options with similar resolution and hardware.

DRI Ranges

See a specific subject's identity, activity, or personal items.

• Detection：Detect if an object is present.

• Recognition：See what type of object it is (i.e. person, vehicle, airplane).

• Identification：Determine subject affiliation and intent.

Multiple Temperature Measurement Modes

Central, Spot, And Regional Temperature Measurement

Central temperature measurement: View real-time display of the temperature in the center area of the screen.

Spot temperature measurement: Tap the screen, and the temperature of the selected object will be displayed in real time.

Regional temperature measurement: Get a dynamic view of the average temperature, maximum temperature, and minimum temperature displayed in a selected area.

Temperature Alarm With Isotherm And Image Enhancement

Temperature alarm: Monitors the screen temperature in real time. The system prompts the user when the temperature reaches a set threshold.

Isotherm: Set a temperature range and the system will detect any objects within the temperature range specified.

Image enhancement: Supports real-time adjustment of image brightness, contrast, and image details. The system will highlight any objects within the temperature target.

10 Thermal Color Palettes

White Hot | Cold and Hot | Rainbow | Enhanced Rainbow | Ironbow | Lava | Arctic | Searing | Gradation |Heat Detection

Powerful Infrared Thermal Analysis Tool

IRPC TOOL: This free temperature measurement analysis tool is developed specifically for the 640T, and enables users to quickly import images, edit and analyze temperature measurements, and generate detailed reports for sharing and collaboration.

Picture-in-Picture Display Mode

Visual and thermal imagery are combined to help users quickly interpret data and aid in critical decision making.

50MP Ultra-Sensitive Camera

The EVO II Dual 640T V3's RYYB sensor features the Moonlight Algorithm 2.0 that provides excellent noise reduction in limited lighting conditions, further enhancing its 50 megapixel camera to give users more detail for better forensics and analysis.

0.8" Sensor Size

The EVO II Dual 640T V3's 0.8" RYYB CMOS offers up to 144%~233% more surface area when compared to 1/2" or 1/2.3" competitors for maximum details in high-contrast lighting conditions.

RYYB Sensor Technology

RYYB sensor technology moves away from RGB cameras by offering up to 40% more light sensitivity in low light scenarios.

PDAF+CDAF Autofocus System

Never lose sights of your subjects with a combination of PDAF (Phase Detection Auto Focus) and CDAF (Contrast Detection Auto Focus) technology for fast and accurate tracking.

Get The Full Scene

The system supports 16x digital zoom and 4x lossless zoom, providing long-distance image acquisition and detailed insight into scenes safely.

4K HDR For Greater Dynamic Range

4K HDR automatically balances overexposure and underexposure when shooting scenes with too much contrast, producing clearer images with more layers.

SkyLink 2.0 Video Transmission

SkyLink 2.0 is built into the EVO II V3 chipset, expanding the possibilities for your most critical workflows.

9+ Miles

Do more because you can fly further away.

QHD

Incredible video resolution within a mile, meeting most common use cases.

2.4GHz / 5.8GHz / 900MHz

Support tri-band communication with automatic frequency hopping for maximum anti-interference capabilities.
* 900MHz is only applicable for FCC countries.

360° Obstacle Avoidance

Equipped with 19 groups of sensors including 12 visual sensors,the main camera, ultrasound, IMUs and other sensors enable building of three-dimensional maps and path planning in real time.

Practical And Convenient Features

  • Deploy Rapidly

    Deploy in under a minute. The EVO II 640T V3 can go from its case to the air in 45 seconds.

  • No Fly Zones*

    EVO II Dual 640T V3 does not have any no fly zones and will not prevent the pilot from taking off.

  • No Forced Updates**

    EVO II Dual 640T V3 does not need to be on the latest hardware or app version in order to take off unlike other competitors.

  • Non-ITAR

    More export freedoms as the EVO II Dual 640T V3 is not under US's International Traffic in Arms Regulations.
*Please fly safely and consult your local laws and regulations. Autel Robotics is not liable for any unauthorized flights.
**It’s required to update the latest firmware and app to enjoy comprehensive warranty. More information please refer to warranty policy.

Autel Smart Controller V3

Smart Controller V3's 7.9-inch, 2000 nit high-brightness screen is clearly visible even under direct sunlight. SkyLink 2.0 Transmission technology guarantees long-distance operations from up to 9 miles away and enhances anti-interference abilities with triple-band frequency hopping. The customized Android system allows for additional flexibility with 3rd party apps and an IP43 rating ensures all weather performance.
  • 7.9-Inch HD Touch Screen
  • -4 °F to 104 °F Temperature Range
  • 2000 nits Maximum Brightness
  • IP43 Resistance

Broadcast with Live Deck 2

Transmit real-time HD video to a wide-variety of devices, allowing cross-departmental teams enhanced situational awareness and communication which can lead to quicker and better decision making.
  • 1080P/60FPS Video Stream
  • Three Auto-Switch Bands
  • 7.5 Miles Transmission Range
  • IP43 Resistance

      640x512 25Hz New Thermal Imaging Sensor

      Equipped with a 640 x 512 high-resolution thermal imaging camera featuring a 13mm focal length lens and 16x digital zoom, it is easier than ever to observe distant targets. The system uses a new image processing algorithm, making thermal details clearer and more discernible than other options with similar resolution and hardware.

      DRI Ranges

      See a specific subject's identity, activity, or personal items.

      • Detection：Detect if an object is present.

      • Recognition：See what type of object it is (i.e. person, vehicle, airplane).

      • Identification：Determine subject affiliation and intent.

      Multiple Temperature Measurement Modes

      Central, Spot, And Regional Temperature Measurement

      Central temperature measurement: View real-time display of the temperature in the center area of the screen.

      Spot temperature measurement: Tap the screen, and the temperature of the selected object will be displayed in real time.

      Regional temperature measurement: Get a dynamic view of the average temperature, maximum temperature, and minimum temperature displayed in a selected area.

      Temperature Alarm With Isotherm And Image Enhancement

      Temperature alarm: Monitors the screen temperature in real time. The system prompts the user when the temperature reaches a set threshold.

      Isotherm: Set a temperature range and the system will detect any objects within the temperature range specified.

      Image enhancement: Supports real-time adjustment of image brightness, contrast, and image details. The system will highlight any objects within the temperature target.

      10 Thermal Color Palettes

      White Hot | Cold and Hot | Rainbow | Enhanced Rainbow | Ironbow | Lava | Arctic | Searing | Gradation |Heat Detection

      Powerful Infrared Thermal Analysis Tool

      IRPC TOOL: This free temperature measurement analysis tool is developed specifically for the 640T, and enables users to quickly import images, edit and analyze temperature measurements, and generate detailed reports for sharing and collaboration.

      Picture-in-Picture Display Mode

      Visual and thermal imagery are combined to help users quickly interpret data and aid in critical decision making.

      50MP Ultra-Sensitive Camera

       The EVO II Dual 640T V3's RYYB sensor features the Moonlight Algorithm 2.0 that provides excellent noise reduction in limited lighting conditions, further enhancing its 50 megapixel camera to give users more detail for better forensics and analysis.

      0.8" Sensor Size

      The EVO II Dual 640T V3's 0.8" RYYB CMOS offers up to 144%~233% more surface area when compared to 1/2" or 1/2.3" competitors for maximum details in high-contrast lighting conditions.

      RYYB Sensor Technology

      RYYB sensor technology moves away from RGB cameras by offering up to 40% more light sensitivity in low light scenarios.

      PDAF+CDAF Autofocus System

      Never lose sights of your subjects with a combination of PDAF (Phase Detection Auto Focus) and CDAF (Contrast Detection Auto Focus) technology for fast and accurate tracking.

      Get The Full Scene

      The system supports 16x digital zoom and 4x lossless zoom, providing long-distance image acquisition and detailed insight into scenes safely.

      4K HDR For Greater Dynamic Range

      4K HDR automatically balances overexposure and underexposure when shooting scenes with too much contrast, producing clearer images with more layers.

      SkyLink 2.0 Video Transmission

       SkyLink 2.0 is built into the EVO II V3 chipset, expanding the possibilities for your most critical workflows.

      9+ Miles

      Do more because you can fly further away.

      QHD

      Incredible video resolution within a mile, meeting most common use cases.

      2.4GHz / 5.8GHz / 900MHz

      Support tri-band communication with automatic frequency hopping for maximum anti-interference capabilities.       * 900MHz is only applicable for FCC countries.

      360° Obstacle Avoidance

      Equipped with 19 groups of sensors including 12 visual sensors,the main camera, ultrasound, IMUs and other sensors enable building of three-dimensional maps and path planning in real time.

      Practical And Convenient Features

      • Deploy Rapidly

        Deploy in under a minute. The EVO II 640T V3 can go from its case to the air in 45 seconds.

      • No Fly Zones*

        EVO II Dual 640T V3 does not have any no fly zones and will not prevent the pilot from taking off.

      • No Forced Updates**

        EVO II Dual 640T V3 does not need to be on the latest hardware or app version in order to take off unlike other competitors.

      • Non-ITAR

        More export freedoms as the EVO II Dual 640T V3 is not under US's International Traffic in Arms Regulations.
      *Please fly safely and consult your local laws and regulations. Autel Robotics is not liable for any unauthorized flights.
      **It’s required to update the latest firmware and app to enjoy comprehensive warranty. More information please refer to warranty policy.

      Autel Smart Controller V3

      Smart Controller V3's 7.9-inch, 2000 nit high-brightness screen is clearly visible even under direct sunlight. SkyLink 2.0 Transmission technology guarantees long-distance operations from up to 9 miles away and enhances anti-interference abilities with triple-band frequency hopping. The customized Android system allows for additional flexibility with 3rd party apps and an IP43 rating ensures all weather performance.
      • 7.9-Inch HD Touch Screen
      • -4 °F to 104 °F Temperature Range
      • 2000 nits Maximum Brightness
      • IP43 Resistance

      Broadcast with Live Deck 2

      Transmit real-time HD video to a wide-variety of devices, allowing cross-departmental teams enhanced situational awareness and communication which can lead to quicker and better decision making.
      • 1080P/60FPS Video Stream
      • Three Auto-Switch Bands
      • 7.5 Miles Transmission Range
      • IP43 Resistance
          • Aircraft
            Takeoff weight (With propellers and battery) 2.54 lbs (1150 g)
            Max takeoff weight 4.41 lbs (1999 g)
            Size(L*W*H) Folded: 230*130*108 mm; 9.1*5.1*4.3 inches
            Unfolded: 457*558*108 mm;18*22*4.3 inches
            Wheelbase 397 mm
            Maximum service ceiling altitude 7000 m
            Max ascent speed 8 m/s (Ludicrous)
            Max descent speed 4 m/s (Ludicrous)
            Max horizontal flight speed 20m/s (Ludicrous)
            Max flight distance (no wind) 22 km
            Max angular velocity 120°/s
            Max tilt angle 33° (Ludicrous)
            Max flight time (no wind) 38 min
            Max hovering time (no wind) 33 min
            Operating temperature range -4 °F to 104 °F (-10℃ ~ 40℃)
            Maximum resistance to wind 12 m/s (Take-off and landing)
            Operating frequency 902-928MHz (FCC Only)
            2.400-2.4835GHz
            5.725-5.850GHz
            Transmission power (E.I.R.P) 900M
            FCC/ ISED：≤31dBm
            2.4G
            FCC/ ISED：≤32dBm
            SRRC/CE/MIC/RCM：≤20dBm
            5.8G ;
            FCC/ISED/SRRC/MIC：≤33dBm
            CE/ RCM：≤14dBm
            Hovering accuracy Vertical: ±0.1 m (when the visual positioning is working normally);
            ±0.5 m (when GNSS works normally)
            Horizontal: ±0.3 m (when the visual positioning is working normally);
            ±1.5 m (when GNSS works normally)
            GNSS GPS/Beidou/Glonass/Gallieo
            Internal storage 8GB
            SD storage max. support 256GB (UHS-3 or Class 10)
          • Gimbal
            Gimbal 3-axis stabilization
            Mechanical range Tilt: -135° to +45°;
            Pan: -100° to +100°
            Controllable rotation range Tilt: -90° to +30°;
            Pan: -90° to +90°
            Max control speed (Tilt) 300°/s
            Angular Vibration Range ±0.005°
          • Remote controller and image transmission
            Operating frequency 902-928MHz (FCC Only)
            2.400-2.4835GHz
            5.725-5.850GHz
            Transmission power (E.I.R.P) FCC：≤33dBm
            CE：≤20dBm@2.4G，≤14dBm@5.8G
            SRRC：≤20dBm@2.4G，≤33dBm@5.8G/5.7G
            Max Transmission Distance (unobstructed, free of interference) FCC：9.3 miles (15 km)
            CE：5 miles (8 km)
            Display screen 2048x1536 60fps
            Battery 5800mAh
            Operating time ~3 hours (Max. Brightness)
            ~4.5 hours (50% Brightness)
            Charging time 120 minutes
            Internal Storage ROM 128GB

          • Sensing system
            Sensing system type Omnidirectional sensing system
            Forward Accurate measurement range: 0.5-18 m
            Effective sensing speed:<12m/s
            Viewing angle: Horizontal: 60°, Vertical: 80°
            Backward Accurate measurement range: 0.5-16 m
            Effective sensing speed:<12m/s
            Viewing angle: Horizontal: 60°, Vertical: 80°
            Upward Accurate measurement range: 0.5-10 m
            Effective sensing speed:<5m/s
            Viewing angle: Horizontal: 65°, Vertical: 50°
            Downward Accurate measurement range: 0.5-10 m
            Effective sensing speed:<5m/s
            Viewing angle: horizontal: 100°, vertical: 80°
            Left and right Accurate measurement range: 0.5-10 m
            Effective sensing speed:<5m/s
            Viewing angle: horizontal: 65°, vertical: 50°
            Operating Environment Forward, Backward and Sides:
            Surface with clear pattern and adequate lighting (lux > 15)
            Upward:
            Detects diffuse reflective surfaces (>20%)
            (walls, trees, people, etc.)
            Downward:
            Surface with clear pattern and adequate lighting (lux > 15)
            Detects diffuse reflective surfaces (>20%)
            (walls, trees, people, etc.)
          • Thermal camera
            Sensor Uncooled VOx Microbolometer
            Lens FOV H33°V26°
            Focal length 13mm
            Zoom 1 - 16x
            Pixel size 12μm
            Wavelength range 8 - 14μm
            Temperature range High gain mode: -20° to +150°
            Low gain mode: 0° to +550°
            Temperature measurement accuracy ±3℃ or ±3% of reading (whichever is greater)
            @Environmental temperature-20℃~60℃
            Accurate temperature
            measurement distance            		 2-20 meters
            Video resolution 640x512@25fps
            Video format MOV / MP4 (Support H.264/H.265)
            Camera resolution Infrared mode: 640*512
            Picture-in-picture mode: 1920*1080, 1280*720
            Photo mode Single shot
            Burst shooting: 3/5 frames, 3 is the default
            Time Lapse:JPG: 2s/5s/7s/10s/20s/30s/60s
            Photo format JPG (with irg file)
          • Visible light camera
            Sensor 1/1.28"(0.8") CMOS; 50M effective pixels
            Lens FOV: 85°
            35 mm format equivalent focal length: 23 mm
            Aperture: f/1.9
            Focus range: 0.5 m to infinity (with auto focus)
            ISO range Video: 100-64000
            Photo: 100-6400
            Shutter speed Photo mode: 1/8000 ~ 8s
            Other: 1/8000 ~ 1/frame rates
            Zoom 1-16x (up to 4x lossless zoom)
            Photo mode Single shot/Burst shooting/AEB/Time Lapse/HDR imaging
            Maximum photo size 8192*6144（4:3）
            4096*3072（4:3）
            3840x2160（16:9）
            Image Format JPG (default) / DNG / JPG+DNG
            Video format MOV / MP4
            Video resolution 3840x2160P60/P50/P48/P30/P25/P24
            2720x1528P60/P50/P48/P30/P25/P24
            1920x1080P60/P50/P48/P30/P25/P24
            Max bitrate 80Mbps
            Supported file system FAT32/exFAT
          • Battery
            Capacity 7100 mAh
            Voltage 11.55 V
            Battery type LiPo 3S
            Energy 82 Wh
            Weight 365 g
            Charging temperature range 5℃ to 45℃
            Storage temperature and humidity -10~30℃，65±20%RH
            Recommended storage temperature 22-28℃
            Max charging power 93W
            Charging time 90 minutes
          • Charger
            Input 100-240 V, 50/60 Hz, 1.5A
            Output 13.2 V ⎓ 5 A
            5V⎓3A 9V⎓2A 12V⎓1.5A
            Voltage 13.2±0.1V
            Rated power 66W
          • Multi-Charger
            Voltage 13.2 V
            Charging temperature range 5℃ to 45℃

          • Autel EVO II V3 Aircraft with Dual 640T Thermal Sensor
          • Autel V3 7.9” Smart Controller w/ Controller Case
          • Intelligent Flight Battery x3
          • Propellers (Pair) x2
          • Smart Controller USB-C Charging Cable & Power Brick
          • Battery Charger (Wall Cord & Power Converter)
          • Spare Controller Sticks (Pair)
          • Gimbal Cover
          • 32 GB SD Card
          • Smart Controller Hanging Neck Strap
          • EVO II Battery Car Charger
          • EVO II Battery Charging Hub
