FLIR Scion PTM336 Thermal Monocular (60 Hz, 25mm, Black)
Review: 5 - "A masterpiece of literature" by , written on May 4, 2006
I really enjoyed this book. It captures the essential challenge people face as they try make sense of their lives and grow to adulthood.
Categories

FLIR Scion PTM336 Thermal Monocular (60 Hz, 25mm, Black)

Available: In Stock
$3,795.00
  • Order within

Imaging Performance

  • 320x256 BOSON 12µm VOx microbolometer
  • 25mm lens with 9.0x6.5° field of view
  • 60 Hz refresh rate
  • Manual focus with 2.5x magnification
  • 1x, 2x, 4x digital magnification
  • Picture-in-picture zoom

Use and Handling

  • FLIR's TruWITNESS streaming platform provides live encrypted video to command centers
  • NFC, Bluetooth, Wifi capability
  • Quad-VGA 1280x960 FLCOS display
  • Scouting, picture-in-picture, and navigation display modes
  • White Hot, Black Hot, Iron Bow, Rainbow, Graded Fire, and Lava thermal palettes
  • 2GB internal memory and up to 128GB with user-supplied micro-SD card
  • Picture while recording, real-time clock, date/time stamp, auto power off
  • Magnetic compass and accelerometer

Construction Details

  • USB-C power input, video output, file transfer, dock connection
  • Runs on six CR123A batteries, runtime 4.5 hours at 68°F
  • IP67-rated waterproof
  • 1/4"-20 mount
  • Measures 9.4x3.0x2.4", weighs 20.2 ounces

Material# 7TM-01-F320

Specifications

Sensor Size 320 x 256
Refresh Rate 60 Hz
Performance
Magnification Optical: 2.6x
Digital: 1 to 4x
Lens System 25 mm
Angle of View 9 x 6.5°
Eye Relief 16 mm
Connectivity
Wi-Fi Yes
Bluetooth 4.1
Connections 1 x USB Type-C
GPS Yes
NFC Yes
Power & Environmental
Battery 6 x CR123A (Approx. 4.5 Hours)
Physical
Water Resistance Waterproof, IP67
Dimensions 9.4 x 3 x 2.4" / 22.7 x 7.7 x 6.1 cm
Weight 20.2 oz / 572.0 g (with Batteries)

Imaging Performance

  • 320x256 BOSON 12µm VOx microbolometer
  • 25mm lens with 9.0x6.5° field of view
  • 60 Hz refresh rate
  • Manual focus with 2.5x magnification
  • 1x, 2x, 4x digital magnification
  • Picture-in-picture zoom

Use and Handling

  • FLIR's TruWITNESS streaming platform provides live encrypted video to command centers
  • NFC, Bluetooth, Wifi capability
  • Quad-VGA 1280x960 FLCOS display
  • Scouting, picture-in-picture, and navigation display modes
  • White Hot, Black Hot, Iron Bow, Rainbow, Graded Fire, and Lava thermal palettes
  • 2GB internal memory and up to 128GB with user-supplied micro-SD card
  • Picture while recording, real-time clock, date/time stamp, auto power off
  • Magnetic compass and accelerometer

Construction Details

  • USB-C power input, video output, file transfer, dock connection
  • Runs on six CR123A batteries, runtime 4.5 hours at 68°F
  • IP67-rated waterproof
  • 1/4"-20 mount
  • Measures 9.4x3.0x2.4", weighs 20.2 ounces

Material# 7TM-01-F320


Sensor Size 320 x 256
Refresh Rate 60 Hz
Performance
Magnification Optical: 2.6x
Digital: 1 to 4x
Lens System 25 mm
Angle of View 9 x 6.5°
Eye Relief 16 mm
Connectivity
Wi-Fi Yes
Bluetooth 4.1
Connections 1 x USB Type-C
GPS Yes
NFC Yes
Power & Environmental
Battery 6 x CR123A (Approx. 4.5 Hours)
Physical
Water Resistance Waterproof, IP67
Dimensions 9.4 x 3 x 2.4" / 22.7 x 7.7 x 6.1 cm
Weight 20.2 oz / 572.0 g (with Batteries)
